OEM High Pressure Pump In Industries Where Humidity Or RO Is Needed

Leading Manufacturer For Industrial High Pressure  Water Pump Axial Piston Type

10+ years' experience on axial piston pump manufacturer for high pressure ro applications​​​​​​​
Equipped with complete machining equipment​​​​​​​
Top-ranked quality control with 100% inspection rate​​​​​​​
Custom-made service（OEM） available​​​​​​​
OEM HIGH PRESSURE PUMP

What is an OEM High Pressure Pump?

An OEM high pressure pump is one that is produced by a manufacturer with the view to be it being used as a component within a system by the customer for sale to an end user. For a special competitive advantage, here launched three types of pumps, namely HPA, HPC, and HPV, all of which are the same pump, the difference lies in the factory settings:

  • HPA & HPC are fixed displacement, for which the displacement is set at the factory.
  • HPV is variable, one can set it himself after the pump leaves the factory.
  • HPA: High-pressure Pump Anti-Clockwise
  • HPC: High-pressure Pump Clockwise
  • HPV: High-pressure Pump Variable

AWS-HYDRO high-pressure piston water pumps, only stainless steel used, are tailored to tap/fresh water use in the likes of firefighting, dust suppression & water hydraulics.

How Does Stainless Steel High Pressure Pump Work?

HPA/HPC operating ambient temperature: -30 ~ +60℃

If the ambient temperature exceeds the above max. value or the motor is installed at an altitude of more than 1000 meters, the output power of the motor will be reduced, mainly due to low air density and poor heat dissipation of the motor. In these cases, a larger motor is required to meet Higher rated output power.



HPA/HPC fluid temperature: 0 ~ +50℃

The excessive fluid temperature will cause permanent damage to the pump. If it needs to work at other temperatures for a long time, please contact us.



HPA/HPC outlet check valve & pressure relief valve:

The check valve prevents pump reverse rotation, which may cause permanent damage to the pump, The pressure relief valve can ensure the effective and safe operation of the system within the rated pressure range and prevent the system from overpressure damage.

How does high pressure pump work

Features And Benefits

•  Wide Application Fields Covering:

• Seawater Desalination

• Wastewater ZLD

• Industries where humidity is needed, in the likes of wood, furniture production, printing houses, textile production, glass production etc.

• High pressure water mist firefighting system

• High pressure water cleaning

• Water hydraulic systems, fixed or mobile



• Oil-free, with water as the only cooling and lubricant, eliminating potential cross-contamination between lubricating oil and water.

• Ultra-clean technology with no lubricating oil and no cross-contamination

• Compact structure, easy to assemble, disassemble and maintain

• Excellent corrosion resistance

• Multi-piston design for minimal pulsation

• Widely used in ultrapure water treatment fields

• Longer service life brings ultra-low cost of use

• Excellent Stability



Stainless Steel Piston Pump?

Stainless Steel High Pressure Pump Data Sheet

For PHA/PHC/PHV Series Industrial High Pressure Pumps; Motor-driven Pump; Stainless Steel Pressure Pump

Model 2 3.2 4 6.3 8 10 11.5 12.5
geometric displacement (cc/rev) 2 3.2 4 6.3 8 10 11.5 12.5
Minimum output pressure（barg） 30 30 30 30 30 30 30 30
Maximum output pressure（barg） 140 140 140 140 160 160 160 160
Continuous inlet pressure（barg） 0-4 0-4 0-4 0-4 0.1-5 0.1-5 0.1-5 0.1-5
Minimum speed (rpm) 700 700 700 700 700 700 700 700
Maximum speed (rpm) 1800 1800 1800 1800 3000 3000 3000 3000
700 rpm Flow at maximum working pressure (L/min) 0.3 1.3 1.9 3.7 5 6.3 7.2 7.9
1000 rpm Flow at maximum working pressure (L/min) 1 2.3 3.2 5.6 7.2 9.1 10.4 11.4
1500 rpm Flow at maximum working pressure (L/min) 2 3.9 5.2 8.7 11 13.8 15.8 17.3
2000 rpm Flow at maximum working pressure (L/min) - - - - 14.8 18.6 21.4 23.3
3000 rpm Flow at maximum working pressure (L/min) - - - - 22.8 28.5 32.8 35.6
1500 rpm Power consumption at maximum operating pressure (KW) 0.9 1.4 1.7 2.6 3.4 4.2 4.9 5.3
Fluid temperature (℃) 2-50 2-50 2-50 2-50 2-50 2-50 2-50 2-50
Ambient temperature (℃) 0-50 0-50 0-50 0-50 0-50 0-50 0-50 0-50
Noise (dB) 76 76 76 76 76 76 76 76
Weight (kg) 4.5 4.5 4.5 4.5 8.6 8.6 8.6 8.6
Integrated Rinsing Valve NO NO NO NO NO NO NO NO
Model 20 25 32 40
geometric displacement (cc/rev) 20 25 32 40
Minimum output pressure（barg） 30 30 30 30
Maximum output pressure（barg） 160 160 160 160
Continuous inlet pressure（barg）700-1800RPM 0-5 0-5 0-5 0-5
Continuous inlet pressure（barg）1800-3600RPM 1-5 1-5 1-5 1-5
Minimum speed (rpm) 700 700 700 700
Maximum speed (rpm) 3600 3600 3600 3000
1000 rpm Flow at maximum working pressure (L/min) 18.0 22.5 28.8 36.0
1500 rpm Flow at maximum working pressure (L/min) 27.0 33.7 43.1 54.0
1800 rpm Flow at maximum working pressure (L/min) 32.4 40.6 51.9 64.9
3000 rpm Flow at maximum working pressure (L/min) 54.5 68.0 87.0 110.0
3600 rpm Flow at maximum working pressure (L/min) 65.1 82.0 104.1 /
1500 rpm Power consumption at maximum operating pressure (KW) 7.2 9.0 11.5 14.5
1800 rpm Power consumption at maximum operating pressure (KW) 8.7 10.8 13.9 17.5
Fluid temperature (℃) 2-50 2-50 2-50 2-50
Ambient temperature (℃) 0-50 0-50 0-50 0-50
Mechanical Efficiency at max. pressure 0.9 0.9 0.9 0.9
Noise (dB) 1500/3000RPM 78 / 85 78 / 85 78 / 85 78 / 85
Weight (kg) 14.7 14.7 14.7 14.7
Integrated Rinsing Valve NO NO NO NO
Model 50 65 71 81 100
geometric displacement (cc/rev) 50 65 71 81 100
Minimum output pressure（barg） 30 30 30 30 30
Maximum output pressure（barg） 160 160 160 160 130
Continuous inlet pressure（barg） 0-5 0-5 0-5 0-5 0-5
Minimum speed (rpm) 700 700 700 700 700
Maximum speed (rpm) 1800 1800 1800 1800 1500
1000 rpm Flow at maximum working pressure (L/min) 46.5 60.5 66.0 75.3 93.0
1200 rpm Flow at maximum working pressure (L/min) 55.8 72.6 79.2 90.35 111.6
1500 rpm Flow at maximum working pressure (L/min) 71.3 92.6 101.2 115.4 142.5
1800 rpm Flow at maximum working pressure (L/min) 85.9 106.5 118.0 136.0 /
1500 rpm Power consumption at maximum operating pressure (KW) 19.0 24.7 27.0 30.8 30.9
1800 rpm Power consumption at maximum operating pressure (KW) 22.8 29.7 32.4 37.0 /
Fluid temperature (℃) 2-50 2-50 2-50 2-50 2-50
Ambient temperature (℃) 0-50 0-50 0-50 0-50 0-50
Mechanical Efficiency at max. pressure 0.95 0.95 0.95 0.95 0.95
Noise (dB) 80 80 80 80 80
Weight (kg) 24.8 24.8 24.8 24.8 25
Integrated Rinsing Valve NO NO NO NO NO

Stainless Steel Piston Pump Installation Size Parameters

HPC2-6.3 Water High Pressure Pump
Models cover: HPC140 - 2W, HPC140 - 3.2W, HPC140 - 4W, HPC140 - 6.3W
"W" stands for Tap Water;

Working Pressure range: 30 bar to 140 bar
"HPA" stands for High-pressure Pump Anti-Clockwise;
"HPC" stands for High-pressure Pump Clockwise
HPC8-12.5 water high pressure pump
Models cover: HPC160 - 8W, HPC160 - 10W, HPC160 - 11.5W, HPC160 - 12.5W
"W" stands for Tap Water;

Working Pressure range: 30 bar to 160 bar
"HPA" stands for High-pressure Pump Anti-Clockwise;
"HPC" stands for High-pressure Pump Clockwise
HPC20-40 Stainless Steel Piston Pump
Models cover: HPC160 - 20W, HPC160 - 25W, HPC160 - 32W, HPC160 - 40W
"W" stands for Tap Water;

Working Pressure range: 30 bar to 160 bar
"HPA" stands for High-pressure Pump Anti-Clockwise;
"HPC" stands for High-pressure Pump Clockwise
HPC50-100 High Pressure Piston Water Pump
Models cover: HPC160 - 50W, HPC160 - 65W, HPC160 - 71W, HPC160 - 81W, HPC130-100W
"W" stands for Tap Water;

Working Pressure range: 30 bar to 160 bar
"HPA" stands for High-pressure Pump Anti-Clockwise;
"HPC" stands for High-pressure Pump Clockwise

High Pressure Piston Pump In Possible Applications


OEM High Pressure Piston Water Pump Packing

Why WE VALUE PACKING

All OEM high pressure piston water pumps we supplied are axial stainless steel piston pumps, which are wildly used in industries where humidity is needed, in the likes of wood, furniture production, printing houses, textile production, glass production etc; or, as a vital component for seawater desalination systems. From an economical point of view, we try to help customers save and control freight costs.
ABOUT US
SERVICE

Welcome To Send Inquiry to Us and Let's Make a Win-Win Business Together!

Documents for China high pressure pump HPA/HPC/HPV series

  • User Manual HPCW Series 2-100 HPP Pump model -20260119.pdf

  • User Manual HPCT Series 2-100 HPP Pump -20250819.pdf

FAQs

  • Axial Piston Pump Working Principle
    加 Created with Sketch.
    形状 Created with Sketch.

    The principle of the piston pump is that when the speed is high, the pressure is low. for example, if the max pressure is 160bar, then when running at this point, the speed range is 700-1800rpm; while if the pressure is under or equal to 80bar, then at this point, the speed range is 700-3450rpm.

  • How do you determine the piston pump rotation direction?
    加 Created with Sketch.
    形状 Created with Sketch.

    The piston pumps are marked in the rotation direction. But motors can run forward or reverse. So, before starting, or when energizing and wiring, it is a must to pay attention to the driving direction of the motor; The driving direction of the motor should be consistent with that of the piston pump.

  • Axial Piston Pump HPA Series Troubleshooting
    加 Created with Sketch.
    形状 Created with Sketch.

    If it is the quality problem of the piston water pump itself, we will provide a new pump for free to replace the old pump. According to the order quantity, we would provide more convenient solutions to help customers. LET'S TALK!

Specifications Guide

High Pressure Piston Water Pump | Stainless Steel Piston Pump

Product Model High Pressure pump HPA/C Model High Pressure pump Weight [kg] High Pressure pump Typical Flow [m3/h] High Pressure pump Typical Speed [rpm] High Pressure pump Speed Range [rpm]  High Pressure pump Power Requirement @160 bar, 1500RPM Types of pumps High Pressure pump Details
2 AWS180B0031L 4.5 0.12 1500 700-1800 - Axial Piston Pump View Details <<
3.2 AWS180B0077L 4.5 0.23 1500 700-1800 - Axial Piston Pump View Details <<
4 AWS180B0030L 4.5 0.31 1500 700-1800 - Axial Piston Pump View Details <<
6.3 AWS180B0029L 4.5 0.52 1500 700-1800 - Axial Piston Pump View Details <<
8 AWS180B0023L 8.6 0.66 1500 700~3000 3.4KW Axial Piston Pump View Details <<
10 AWS180B0032L 8.6 0.82 1500 700~3000 4.2KW Axial Piston Pump View Details <<
11.5 AWS180B0007L 8.6 0.94 1500 700~3000 4.9KW Axial Piston Pump View Details <<
12.5 AWS180B0033L 8.6 1.04 1500 700~3000 5.3KW Axial Piston Pump View Details <<
20 AWS180B0019L 14.72 1.65 1500 700~3600 8.5KW Axial Piston Pump View Details <<
25 AWS180B0020L 14.72 2.07 1500 700~3600 10.6KW Axial Piston Pump View Details <<
32 AWS180B0021L 14.72 2.65 1500 700~3600 13.6KW Axial Piston Pump View Details <<
40 AWS180B0095L 14.72 3.31 1500 700~3000 17KW Axial Piston Pump View Details <<
50 AWS180B0085L 24.8 4.27 1500 700~2000 21.9KW Axial Piston Pump View Details <<
65 AWS180B0086L 24.8 5.55 1500 700~1800 28.5KW Axial Piston Pump View Details <<
71 AWS180B0087L 24.8 6.07 1500 700~1800 31.1KW Axial Piston Pump View Details <<
81 AWS180B0088L 24.8 6.92 1500 700~1800 35.5KW Axial Piston Pump View Details <<
100 AWS180B0076L 24.8 8.55 1500 700~1800 43.8KW Axial Piston Pump View Details <<
